MODELS SUPPORTED
Technician’s Notes
Please note that the logic board from your old original disc drive must be transferred over to the disc drive you order from us as there is a key on your Xbox 360’s mainboard that must match the key on the logic board. You can also flash the original key using software like JungleFlasher but this requires a PC and specialized tools. The easiest way is to transfer the PCB, also referred to as the disc drive logic board by removing a few ribbon cables and soldering a few wires. We explain this process in our video guide below.
